Practical Casting Kit: Centrifugal Casting

The Practical Casting Kit: Centrifugal Casting, is an essential educational unit for teaching the fundamentals of centrifugal casting. This unit enables students to develop practical skills in centrifugal casting techniques, facilitating a deep and detailed understanding of the involved processes.

ATENG 12250 — Practical Casting Kit: Centrifugal Casting

• This unit is mounted on a 2 mm thick steel sheet, primed and painted, and hold by a frame of extruded and anodized aluminum, which
  provides a great stiffness and resistance.
• Three-phase motor that does 1.67 A with 2700 rpm.
  Variator that controls the motor. It can turn with a maximum frequency of 50 Hz (which
• corresponds to 3000 rpm approximately) and a minimum one of 5 Hz. The motor turning
  speed can be changed from this variator. Turning anticlockwise direction.
• Stainless steel cast axis with a diameter of 20 mm.
• The cast is cylindrical and is made of aluminum, outer diameter of 82 mm, inner diameter of
• 70 mm and length of 150 mm.
• The cast useless length is 110 mm, once the lids have been placed.
  The cast is made with a little cone-shape to make easier the extraction of piece towards the
  inlet side. ATENG 12250 detail
  Small saucepan in which the tin can be heated.
  Crucible from which the tin can be pour in order to the start the experiment.
  2 Kg tin bar.
  Thermometer.
  All instruction set is supplied ready to use, including enough test material.
  All material is recoverable.
  Cables and accessories, for normal operation.
  Detail of finished cast
