Precision Conductivity Meter for Oil Fuel and Petroleum Testing Instruments

The Aviation Fuel Conductivity Tester determines the rest electrical conductivity of aviation fuels and other similar low-conductivity hydrocarbon liquids within the range of 0.1 to 2000 pS/m. The instrument measures conductivity using a 100 mL sample introduced between two concentric electrodes in the conductivity cell. A sensitive DC ammeter measures the resulting current, which is converted and digitally displayed in picosiemens per meter (pS/m), also known as conductivity units (CU), where 1 CU = 1 pS/m. The cell features a stable, calculable cell constant and an enclosure design that eliminates the need for external screening against stray electrical fields. Electronic circuitry automatically samples and holds readings, while an internal self-check function verifies the electronic circuits. The instrument includes a large five-digit LCD, an easy-to-disassemble and clean conductivity cell, and a low-battery indicator. It is powered by six standard 9 V batteries and can be modified for higher conductivity ranges. Optional sample temperature measurement is also available. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for aviation fuel conductivity testing applications.

Measurement Range:

• 0.1 to 2000 pS/m
• Higher conductivity ranges available through modification

Sample Volume:

• 100 mL

Measurement Principle:

• Two concentric electrodes in the conductivity cell
• DC voltage applied between the electrodes
• Sensitive DC ammeter measures the resulting current
• Automatic conversion and digital display of conductivity
• Conductivity units: 1 CU = 1 pS/m

Display and Electronics:

• Large five-digit liquid crystal display
• Automatic sampling and reading hold
• Internal electronic circuit self-check calibration
• Low-battery indicator

Conductivity Cell:

• Stable and calculable cell constant
• Enclosed design to minimize interference from stray electrical fields
• Easy disassembly and cleaning
• Accurate measurement of a 100 mL sample

Power Supply:

• Six standard 9 V batteries

Optional Features:

• Sample temperature measurement
• Modification for higher conductivity ranges

Standard Accessories:

• Electronics assembly
• Batteries
• Console
• Instruction manual on CD
• Conductivity cell
• Certificate of calibration
• Interconnecting cable assembly
