Precooling Apparatus for Oil Fuel and Petroleum Testing Instruments

The Liquefied Petroleum Gas Volatility and Residue Tester determines the volatility of liquefied petroleum (LP) gases by allowing a precooled sample to weather under specified conditions and recording the temperature at which 95% of the sample has evaporated. Residue determination is performed by weathering a precooled sample and measuring the volume remaining at 100°F (37.8°C). The apparatus consists of a brass cooling vessel with a built-in 20 ft (6 m) copper cooling coil. It includes compression fittings and a 1/8-inch needle valve at the downstream end. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for liquefied petroleum gas volatility and residue testing applications.

Construction:

• Brass cooling vessel
• Built-in copper cooling coil
• Cooling coil length: 20 ft (6 m)
• Compression fittings
• 1/8-inch needle valve at the downstream end

Residue Test Temperature:

• 100°F (37.8°C)

Dimensions (Diameter × Height):

• 3 × 11¾ inches (7.6 × 29.9 cm)
