Pressure sensor characteristic Physics Lab Experiment Setup

This experiment system is designed for studying pressure sensor characteristics, density measurement techniques, and liquid surface tension phenomena. It provides a comprehensive platform for investigating force sensing, density determination, and electronic weighing applications. The system combines precision sensing technology with specialized experimental accessories, making it suitable for physics and instrumentation laboratories.

Physics Lab Experiments from Atico Exports.

Experimental Principle and Content

• Measurement of Pressure Sensor Characteristics
• Measurement of Liquid Surface Tension
• Measurement of Solid Density
• Design and Development of Electronic Scales
• Measurement of Liquid Density

Voltage Output :

• 3–15 V
• Continuously Adjustable
• 3½-Digit Digital Display

Voltage Measurement :

• 0–199.9 mV
• 3½-Digit Digital Display

Sensor Measurement Range :

• 0–100 g

Force Sensor Measurement Range :

• 0–10 g

Pressure Sensor Experimental Device :

• Lift-Type Pressure Sensor Test Unit

Liquid Film Height Measurement Device :

• Micrometer-Based Measurement System

Surface Tension Measurement Device :

• Dedicated Surface Tension Experimental Unit

Liquid Container :

• Transparent Container for Liquid Experiments

Surface Tension Accessory Set :

• Surface Tension Box with Dedicated Accessories

Solid Density Measurement Unit :

• Dedicated Float and Density Measurement Accessories

Liquid Density Measurement System :

• Real-Time Liquid Density Measurement Template

Standard Weights :

• Calibrated Weight Set Included

Electronic Scale Design Module :

• Experimental Template
• Dimensions: 50 × 220 × 300 mm
• Zero Adjustment
• Adjustable Amplification
