PROCTOR MOULDS AND HAMMERS

Standards Compliance :

• Complied as per ASTM D 698, D 1557, BS & AASHTO T 99, T180, T134, CNR No. 69, EN 13286-2, 13286-4, BS 1377-4, BS 1924-2

Application :

• Used for determining the relationship between the moisture content and density of compacted soils.

Construction :

• Made of plated steel, includes collar, mould body and base plate.
• Rammers are used to compact the soil sample in the Proctor Moulds and made of plated steel.

Models :

• Different models are available conforming to the relevant standards.

Internal Diameter (mm) :

• AECE2556/A - 101.6 ° 0.4
• AECE2532/A - 152.4 ° 0.7
• AECE2556/C - 100 ° 1
• AECE2532/B - 150 ° 1
• AECE2556/B - 105 ° 0.5
• AECE2532/C - 152.4
• AECE2022 - 152 ° 0.5

Body Height (mm) :

• AECE2556/A - 116.4 ° 0.5
• AECE2532/A - 116.4 ° 0.5
• AECE2556/C - 120 ° 1
• AECE2532/B - 120 ° 1
• AECE2556/B - 115.5 ° 0.5
• AECE2532/C - 115.5
• AECE2022 - 127 ° 1

Volume (cm°) :

• AECE2556/A - 944 ° 14
• AECE2532/A - 2124 ° 25
• AECE2556/C - 942
• AECE2532/B - 2120
• AECE2556/B - 1000
• AECE2532/C - 2106
• AECE2022 - 2303

Weight (kg) :

• AECE2556/A - 4.5
• AECE2532/A - 7.5
• AECE2556/C - 5
• AECE2532/B - 8
• AECE2556/B - 5
• AECE2532/C - 7.5
• AECE2022 - 8.5
