Pulse Vacuum Autoclave ALB608

Pulse Vacuum Autoclave is a horizontal sterilization unit designed for efficient and reliable sterilization processes. It features a lifting-type door system and utilizes pure steam and clean air as sterilization media. The unit combines vacuum dehumidification with jacket heating for effective drying of sterilized items. An advanced temperature, time, and F0 dual control system ensures precise process management and consistent sterilization performance. Laboratory Equipment from Atico Exports.

• Sterilization of clothes and fabrics
• Metal instruments
• Biological products
• Utensils
• Medical appliances
• Medical dressings
• Herbal medicines
• Culture media
• Botany laboratories
• Zoology laboratories
• Biochemistry laboratories
• Forensic laboratories
• Pharmaceutical industries
• Cytology laboratories
• Immunology laboratories
• Genetics laboratories
• Bioengineering facilities
• Healthcare and sanitary facilities

Steam Consumption :

• 25 kg

Cooling Water :

• 200 kg

Vacuum :

• 0.25 m³

Door System :

• Lifting Type

Power :

• 3 kW

Water Pressure Range :

• 0.15 MPa to 0.3 MPa

Steam Pressure Range :

• 0.4 MPa to 0.8 MPa

Compressed Air :

• 0.5 MPa to 0.8 MPa

Temperature :

• 139 °C

Chamber Dimensions :

• 1000 × 500 × 500 mm

External Dimensions :

• 1400 × 1250 × 1800 mm

Net Weight :

• 700 kg

• Data storage and process management
• PLC touchscreen for convenient operation
• Acid-resistant stainless steel chamber
• Independent data recording
• Compressed air sealing technology
• Lifting-type door system
• Vacuum dehumidification system
• Jacket heating for effective drying
• Temperature, time, and F0 dual control system
• Reliable sterilization performance
