Pulse Vacuum Autoclave ALB631

Pulse vacuum autoclave is an 80 L vertical unit equipped with an elevating door. It features one-key operation for the complete procedure and a steam-water inner circulation system to maintain a clean and dry sterilization environment. Designed with a ventilation filter and an individual steam generator, it also includes a PT-TT testing port for easy and convenient operation. Laboratory Equipment from Atico Exports.

• Used for sterilizing clothes, fabrics, metal instruments, biological products, utensils, medical appliances, medical dressings, herbal medicines, culture media, etc.
• Suitable for use in the fields of botany, zoology, biochemistry, forensics, pharmaceuticals, cytology, immunology, genetics, bioengineering, health, and sanitation.

Capacity :

• 80 L

Temperature Range :

• 105 to 134 °C

Operating Temperature :

• 134 °C

Working Pressure :

• 0.22 MPa

Maximum Working Pressure :

• 0.23 MPa

Heating Average :

• ≤ ±1 °C

Timing Range :

• 0 to 99 min / 0 to 99 h 59 min

Display :

• 7-inch touch screen display

Power Consumption :

• Steam generator: 3 kW
• Dry blanket: 2.4 kW / AC 220 V, 50 Hz

Chamber Dimension (Φ × H) :

• Φ 395 × 650 mm

External Dimension (W × D × H) :

• 686 × 556 × 1035 mm

Packaging Dimension (W × D × H) :

• 786 × 656 × 1135 mm

Net Weight :

• 200 kg

Gross Weight :

• 230 kg

• Vertical type pulse vacuum autoclave with elevating door
• Convenient one-key operation for the complete procedure
• Steam-water inner circulation system for a dry environment
• Ventilation filter to prevent contamination
• Individual steam generator ensures energy efficiency
• PT-TT testing port for easy and convenient testing
• Fully automatic control with touch screen display
• Different loading programs to meet various requirements
