Q-Switched Nd YAG Frequency-Tripled Laser System

This Q-switched solid-state laser experiment system is designed to study the principles of pulsed laser operation, electro-optic Q-switching, and nonlinear frequency conversion. It enables students to assemble and align the laser system, measure pulse characteristics, determine the laser threshold, investigate laser modes, and perform crystal angle-matching frequency doubling experiments. Manufactured by Atico Export India.

Experiments :

• Install and Align the Laser System.
• Measure the Laser Output Pulse Width.
• Determine the Laser Threshold and Study Laser Mode Selection.
• Perform Electro-Optic Q-Switch Experiments.
• Investigate Crystal Angle-Matching Frequency Doubling and Measure Output Energy and Conversion Efficiency.

Wavelength :

• 1064 nm
• 532 nm
• 355 nm

Output Energy :

• 500 mJ
• 200 mJ
• 50 mJ

Pulse Width :

• 12 ns

Pulse Repetition Frequency :

• 1 Hz
• 3 Hz
• 5 Hz
• 10 Hz

Output Stability :

• Within ±5%
