Radial and linear heat conduction

Demonstrates material-bound heat transport in solid bodies. This unit allows for the comparison of temperature profiles in both linear (through samples) and radial (through a brass disc) setups.

• investigation of linear and radial heat conduction
• linear setup: 3 measuring objects with 9 temperature points
• radial setup: brass disc with 6 temperature points
• electrical heating and water cooling elements
• software for representation of temperature profiles and data acquisition
