Ramsbottom Carbon Residue Apparatus for Fuel Testing Instrument

The Ramsbottom Carbon Residue Test Furnace is designed to determine the carbon residue of petroleum products under controlled high-temperature conditions. The test evaluates the tendency of petroleum samples to form carbonaceous deposits during evaporation and thermal decomposition.

The apparatus features a thermostatically controlled cast-iron block furnace with a capacity for five coking bulbs. It rapidly reaches the standard test temperature of 550°C (1022°F) and maintains temperature stability within ±1°C. A microprocessor-based temperature controller provides a digital setpoint and temperature display, with selectable °C/°F units.

An integrated overtemperature protection circuit automatically interrupts power if the furnace temperature exceeds the programmed safety limit, protecting both the operator and equipment.

Manufactured by Atico Export for reliable carbon residue testing of petroleum products in fuel testing and quality control laboratories.

• Determination of carbon residue in petroleum products
• Evaluation of the tendency of fuels and oils to form carbon deposits
• Thermal decomposition testing of petroleum samples
• Quality control and characterization of petroleum products
• Laboratory testing in accordance with applicable ASTM and related standards

Furnace Type :

• Cast-iron block

Sample Capacity :

• 5 coking bulbs

Standard Test Temperature :

• 550°C (1022°F)

Maximum Temperature :

• 650°C (1200°F)

Temperature Control Stability :

• ±1°C (±2°F)

Heating Element :

• Ceramic band heater

Heater Power :

• 0–2400 W

Temperature Controller :

• Microprocessor-based control
• Digital temperature display
• °C/°F selection
• Programmable overtemperature cut-off

Dimensions (L × W × H) :

• 16 × 21.5 × 14.5 inches (41 × 55 × 37 cm)

Net Weight :

• 64 lb (29 kg)

• Five-sample testing capacity
• Cast-iron block furnace construction
• Rapid heating to the standard test temperature
• Microprocessor-based temperature control
• Digital setpoint and actual temperature display
• Selectable temperature display in °C or °F
• Temperature stability of ±1°C
• Automatic overtemperature cut-off protection
• Ceramic band heating element
• Designed for controlled high-temperature carbon residue testing
