Rapid Flash Tester Open Cup for Oil Fuel and Petroleum Testing Instruments

The Rapid Open-Cup Flash Point Tester determines the sustained burning characteristics of small liquid samples. It provides rapid flash/no-flash testing using a 2 mL sample, with results available in approximately one minute for flash points below 212°F (100°C). The instrument is suitable for quality assurance, environmental compliance testing, and flammability assessment of paints, fragrances, hydrocarbons, and other liquids. The open-cup model is designed to evaluate the sustained burning characteristics of mixtures containing flammable and non-flammable liquids or liquids with widely differing flash points. It features semi-automatic operation, a digital temperature display, and a sample cup accommodating 2 mL or 4 mL samples. The tester quickly stabilizes at the selected temperature, allowing the test flame to be applied and the result observed. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for flammability testing applications.

• Paints and coatings
• Fragrances
• Hydrocarbons
• Other liquid samples
• Quality assurance and environmental compliance testing
• Assessment of sustained burning characteristics in liquid mixtures

Testing Function:

• Sustained burning characteristics
• Flash/no-flash testing

Temperature Range:

• Ambient to 212°F (100°C)

Test Duration:

• Approximately 1 minute for flash/no-flash testing below 100°C (212°F)

Sample Volume:

• 2 mL or 4 mL

Standard Accessories:

• Thermometer, range 32°F to 230°F (0°C to 110°C)
• Syringe

Dimensions (L × W × H):

• 15 × 23.4 × 6.3 inches (38.1 × 8.6 × 16.2 cm)

Net Weight:

• 10 lbs (4.6 kg)

• Simple operation
• Semi-automatic testing
• Digital temperature display and setting
• Rapid stabilization at the selected test temperature
• Open-cup testing method
