Rectifiers Half, Full & Bridge

EXPERIMENT: REALIZATION OF HALF-WAVE, FULL-WAVE & BRIDGE RECTIFIER AND DETERMINATION OF ITS EFFICIENCY AND RIPPLE FACTOR WITH AND WITHOUT FILTERS

EXPERIMENT SETUP CONSISTS OF:

• Rectifiers Kit – With half-wave, full-wave and bridge rectifier circuits, set of capacitors and resistors for filters, load variation, digital current and voltmeter AC/DC
• Center-Tapped Transformer – Mounted on metal base, output 7-0-7 V AC
• Set of Patch Cords

Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.
