Refrigerated and Heating Circulator

Refrigerated and Heating Circulator operates within a temperature range of 25°C to 200°C for versatile cooling and heating applications. The closed-type compressor provides efficient refrigeration by sealing the cooling circuit from external contaminants. It features a distillation tank with a 17 L capacity for liquid separation and purification. The user-friendly 7-inch color touchscreen simplifies operation. Manufactured by Atico Export India.

• Laboratory temperature control
• Industrial temperature control
• Chemical reaction processes
• Material testing
• Liquid heating and cooling applications
• Thermal management for efficient processing

Standard Accessories :

• Connecting pipes (2 pcs)

Optional Accessories :

• PLC control system

Technical Specifications :

Temperature Range :

• 25°C to 200°C

Temperature Accuracy :

• ±1°C

Ambient Temperature :

• ≤30°C

Optimal Humidity :

• 0.6

Heating Power :

• 6 to 7 kW

Cooling Capacity :

• 11,500 W (at room temperature)
• 8,600 W (at 0°C)
• 3,200 W (at -25°C)

Temperature Sensor :

• PT100

Safety Features :

• Overvoltage protection
• Overcurrent protection
• Overheating protection
• Leakage protection
• Ground protection

Compressor Type :

• Closed

Compressor Power Consumption :

• 3.75 kW

Compressor Quantity :

• 5

Refrigerant :

• R404

Chiller Type :

• Airtight air cooling

Chiller Fan Type :

• Axial flow fan with outer rotor

Number of Fans :

• 1

Distiller Type :

• Plate heat exchanger

Distiller Tank Volume :

• 17 L

Distiller External Circulation Connection :

• G3/4

Circulating Pump Type :

• Vortex pump

Circulating Pump Power Consumption :

• 370 W

Circulating Pump Current :

• 3.5 A

Pump Performance :

• 12 m head lift
• 35 L/min flow rate

Phase Number :

• 3 Phase

Total Power Consumption :

• 12 kW

Power Supply :

• 220 V / 380 V, 480 V, 50 Hz

Dimensions (L × W × H) :

• 770 × 670 × 1180 mm

Packaging Dimensions :

• 840 × 760 × 1340 mm

Net Weight :

• 170 kg

Gross Weight :

• 220 kg

• Integrated pre-cooling, refrigeration, and heating system
• Fast cooling capability
• Efficient fully brazed plate heat exchanger
• Durable SPCC construction
• Axial flow fan for optimal circulation
