Refrigerated Kinematic Viscosity Bath with Optical Flow Detection System for Fuel Testing Instrument

The Low-Temperature Kinematic Viscosity Bath is designed to measure the kinematic viscosity of petroleum and petrochemical products using calibrated glass capillary viscometers under precisely controlled temperature conditions. It supports viscosity testing under gravity or vacuum in accordance with applicable test methods.

The system accommodates four glass capillary viscometers and supports automated viscosity measurement when equipped with compatible optical detection assemblies. Optical sensors measure sample flow, while the integrated control system calculates viscosity results and records sample efflux times.

The bath features microprocessor-based PID temperature control, dual digital displays, and a two-decimal calibration offset. A clear, evacuated Dewar flask and glare-free fluorescent backlighting provide excellent visibility during testing. Air-cooled hermetic compressors using CFC-free refrigerants provide efficient low-temperature operation.

Integrated safety systems include primary and redundant overtemperature protection, probe-disconnection protection, and a low-liquid-level sensor. These safety circuits interrupt heater power and prevent operation until the fault is corrected.

Manufactured by Atico Export for precise low-temperature viscosity testing in petroleum, petrochemical, and research laboratories.

• Kinematic viscosity measurement of petroleum products
• Low-temperature viscosity testing of fuels and lubricants
• Viscosity analysis of petrochemical products
• Automated measurement of sample efflux time
• Quality control and research laboratory testing

Testing Capacity :

• Four glass capillary viscometers

Viscometer Ports :

• Four round ports, 2 inches (51 mm) in diameter
• One additional port for the thermometer holder

Bath Dimensions :

• 9.5 inches diameter × 12 inches depth (24 cm diameter × 30 cm)

Bath Capacity :

• 3.7 US gallons (14 L)

Temperature Range :

• Low-temperature configuration: 15°C to −30°C (59°F to −22°F)
• Extended low-temperature configuration: 15°C to −70°C (59°F to −94°F)

Temperature Display Resolution :

• 0.1°C / 0.1°F

Temperature Calibration Resolution :

• 0.01°C / 0.01°F

Temperature Control Accuracy and Uniformity :

• Exceeds applicable ASTM requirements throughout the operating range

Cooling System :

• Air-cooled hermetic compressor

Safety System :

• Primary overtemperature protection
• Redundant adjustable overtemperature controller and sensor
• Heater cut-off upon primary probe disconnection
• Low-liquid-level sensor
• Fault-latching protection circuits

Net Weight :

• Low-temperature configuration: 176 lb (79.83 kg)
• Extended low-temperature configuration: 278 lb (126.1 kg)

Standard Accessories :

• Four Delrin port covers
• Thermometer holder

Optional Accessories :

• Optical detection assemblies
• Compatible glass capillary viscometer tubes
• Rectangular viscometer ports, available on special order

• Capacity for four glass capillary viscometers

• Optical flow detection capability

• Supports automatic viscosity calculation with compatible optical sensors and software

• Microprocessor-based PID temperature control

• Dual digital displays for temperature monitoring

• Two-decimal temperature calibration offset

• Clear, evacuated Dewar flask for the bath medium

• Glare-free fluorescent backlighting

• Insulated steel cabinet with polyester-epoxy finish

• Chemical-resistant working surface

• Adjustable leveling feet

• Clear, distortion-free front viewing window

• Primary and redundant overtemperature protection

• Heater cut-off in the event of primary probe disconnection

• Integrated low-liquid-level protection

• Fault-latching safety circuits

• Optional rectangular viscometer ports available on special order
