Reichert Tester for Oil Fuel and Petroleum Testing Instruments

The Reichert Wear and Extreme Pressure Tester determines the wear-preventive (WP) and extreme-pressure (EP) properties of lubricants and additives. The test rig consists of a rigidly mounted test roller pressed against a friction wheel in a cross-cylinder contact configuration. The friction wheel is partially submerged in the lubricant bath, and the test load is applied using dead weights. A dual-measurement load cell measures the normal load and frictional force. A contact-type acoustic emission detector monitors scratching noise at the contact surface. The lubricant chamber incorporates a heater and temperature control system for operation from ambient temperature to the selected setpoint. Online data acquisition software records normal load, frictional force, coefficient of friction, sound level, lubricant bath temperature, and sliding distance for analysis and comparison. An optical microscope with a CCD camera-based image acquisition system is provided to examine wear scars and measure their major and minor axes for calculating scar diameter. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for lubricant wear and extreme-pressure testing applications.

• Evaluation of lubricant wear-preventive properties
• Determination of extreme-pressure properties of lubricants and additives
• Measurement of frictional force and coefficient of friction
• Wear scar analysis and measurement
• Monitoring of scratching noise during testing

Frictional Force:

• Up to 500 N

Rotational Speed:

• Up to 1500 RPM
• Continuously variable through an AC frequency drive

Temperature Range:

• Ambient to 120°C

Temperature Sensor:

• RTD

Sliding Speed:

• 0.85–2.50 m/s

Friction Wheel Diameter:

• 35 mm

Test Roller Dimensions:

• 12 mm diameter × 18 mm length

Preset Timer:

• Up to 99 hours, 59 minutes, and 59 seconds

Acoustic Sensor:

• Measures contact noise level
• Least count: 10 μ

Dial Indicator:

• Range: 10 mm
• Measures radial wear

Sample Volume:

• Approximately 25 mL

Data Acquisition and Analysis:

• Online data acquisition software
• Measurement of normal load and frictional force
• Calculation of coefficient of friction
• Monitoring of sound level, oil bath temperature, and sliding distance
• Test data analysis and comparison

Wear Scar Measurement System:

• Optical microscope
• CCD camera-based image acquisition system software
• PC-based viewing and measurement of wear scars
• Measurement of major and minor axes for scar diameter calculation
• PC not included

Standard Accessories:

• Data acquisition software on CD
• Optical microscope with CCD camera-based image acquisition software
• Dial gauge
• Test rolls:
  • Brass: 25
  • Copper: 25
  • Aluminium: 25
  • Bearing steel: 25
  • Bearing-steel friction wheels: 25
