Relative Density Test

Relative density relates the dry density of cohesionless soil to the maximum and minimum densities. The degree of compaction is sometimes called state of densification.
This method, in the EN standard, covers the determination of the maximum dry density and water content of cohesionless materials when compacted using a vibrating table. Materials for which this method is applicable may contain up to 12 % by mass fines (<0.063 mm). The maximum particle size of the materials to be tested is 80 mm. This method applies to mixtures to be used in road construction.
The ASTM also specify that it is used for the determination of the relative density of cohesionless soil for which impact compaction will not produce a well-defined moisture density relationship curve and where the maximum density of impact method will generally be less than by vibratory method.

Standards Compliance :

• Complied as per EN 13286-5, ASTM D4253, ASTM D4254

Models :

• The two versions AECE2329/A Conforming to EN and AECE2329/B Conforming to ASTM are practical identical except for the ° 0.1 cu.ft mould.

AECE2329/A Relative Density Test Set :

• AECE2329/A Relative Density Test Set Supplied complete with 762°762 mm Vibrating Table (3600 rpm) with adjustable vibration magnitude, 0.1 cu.ft. Relative Density Mould Set (Mould, Circular surcharge weight with handle, Surcharge base plate with handle and detachable sleeve with clamp assembly) and Relative Density Gauge Set.

AECE2329/B Relative Density Test Set :

• AECE2329/B Relative Density Test Set Supplied complete with 762°762 mm Vibrating Table (3600 rpm) with adjustable vibration magnitude, 0.1 cu.ft. Relative Density Mould Set (Mould, Circular surcharge weight with handle, Surcharge base plate with handle and detachable sleeve with clamp assembly) and Relative Density Gauge Set.

Relative Density Gauge Set :

• Relative Density Gauge Set is supplied with Analog displacement dial gauge (50 ° 0.01 mm division, 0–100 scale) with holder and Metal calibration bar.

Ordering Information :

• Relative Density Pouring Funnel Set is required for loose placement of 9.5 mm and finer granular soils in the Mould Set. The Funnel Set includes two 152 ° 305 mm metal cylinders, each with funnel and 152 mm long delivery spout attached to one end. Spouts are 25.4 mm and ° 12.7 mm. The pouring devices are mandatory according to ASTM D4253 and should be ordered separately.
