Resistance thermometer design Physics Lab Experiment Setup

This experiment system is designed for studying the temperature characteristics of metallic resistance elements and the principles of resistance-based temperature measurement. It enables users to analyze the relationship between resistance and temperature and develop practical resistance thermometer designs. The system combines accurate temperature control with precision voltage measurement, making it suitable for educational and laboratory applications.

Manufactured by Atico Export India.

Experimental Principle and Content

• Measurement of Metal Resistance Temperature Characteristics
• Design and Development of Resistance Thermometers

Digital Temperature Sensor :

• Measurement Range: -50°C to 150°C
• Accuracy: ±0.1°C

Intelligent Temperature Controller :

• Temperature Control Range: 50°C–120°C
• Adjustable Setting
• Stability: ±0.1°C

Constant Temperature Stability :

• ≤ ±0.1°C

Voltage Measurement :

• Ranges: 0–1.999 V
• 0–19.99 V
• 3½-Digit Digital Display

Experiment Module :

• Dedicated Resistance Thermometer Design Experiment Module
