Rheology Viscometer petroleum testing instruments by ATICO EXPORT

The 8-speed electronic oilfield viscometer is extensively used worldwide in both field and laboratory applications for precise measurement of the rheological properties of drilling fluids and cement.

Instrument geometry :

• True Couette coaxial cylinder

Speed accuracy :

• 0.1 RPM

Motor speeds :

• 8 fixed speeds (600, 300, 200, 100, 60, 30, 6 and 3 RPM)

Readout :

• Direct dial

Shipping dimensions :

• 22 × 14 × 10 inches (56 × 36 × 25 cm)

Shipping weight :

• 25 lb (11 kg)

Power requirement :

• 115 / 230 VAC, 50/60 Hz

Power requirements :

• 13 - 16 VDC

Components :

• Lens for cover
• Bob shaft
• Fuse, 4 Amp, 1 1/4" × 1/4"
• Light assembly
• Stainless steel cup
• Wrench for bob shaft
• Rotor sleeve, R1
• Bearing shield
• Bob, B1
• Bearing for main shaft
• Torsion spring assembly, F1.0
• Bob shaft bearing, shielded
• Retainer ring, external
• Power cord, 115 Volt

Optional :

• Power cord for 12 Volt cigarette lighter adapter
• Spare parts kit
• Calibration check kit
• Rotor sleeve, R1, closed cup, 316 stainless steel
• Calibration fluid, 100 cP, 16 oz
• Calibration fluid, 50 cP, 16 oz
• Power cord, 230 Volt

• Speeds are easily changed with a control knob
• Shear stress values displayed on a lighted magnified dial for easy reading
• Motor RPM continuously monitored and automatically adjusted by the electronic speed regulator to maintain constant shear rate under varying power and fluid shear conditions
• Suitable for both field and laboratory use
• Motor-driven electronic package provides accurate and versatile operation
• Conventional oilfield rotor, bob and torsion springs maintain rheology history and reproducibility between instruments and laboratories
• Wide variety of bob and torsion springs available for different fluid tests
• Operates worldwide without flipping switches or rewiring
• Threaded rotor mechanically attaches consistently every time
• Available with retractable legs for placement in kits
