Ring And Ball Softening Point Apparatus

Used for determining softening point of bituminous materials by ring and ball method.
The softness of bitumen depends, amongst other factors, on the temperature of the substance, where, as the temperature is raised, the softness of the bitumen increases.

Analog Ring and Ball Test Set Supply

Analog Ring and Ball Test Set is supplied complete with an Analog hotplate with magnetic stirrer, 2 steel balls, Frame (thermometer and ring holder, ball centering guide and bottom plate), 2 brass rings (ASTM or EN (It must be specified at the time of order)), 600 ml glass beaker and max. 110C thermometer.

Digital Ring and Ball Test Set Supply

Digital Ring and Ball Test Set is supplied complete with a Digital hotplate with digital magnetic stirrer (with immersion type temperature sensor with its holder and a stirring bar), 2 steel balls, Frame (thermometer and ring holder, ball centering guide and bottom plate), 2 brass rings (ASTM or EN (It must be specified at the time of order)), 600 ml glass beaker and max. 110C thermometer.

Optional Accessories

Glass or ASTM Thermometers and Pouring Plate should be ordered separately.

STANDARDS COMPLIANCE :

• COMPLIED AS PER EN 1427, ASTM D36, AASHTO T 53

Dimensions (cm) :

• Analog Ring and Ball Test Set - 21x31x40
• Digital Ring and Ball Test Set - 21x31x40

Weight (kg) :

• Analog Ring and Ball Test Set - 4,5
• Digital Ring and Ball Test Set - 4,5

Power Supply :

• Analog Ring and Ball Test Set - 220 V, 50-60 Hz, 1 ph
• Digital Ring and Ball Test Set - 220 V, 50-60 Hz, 1 ph

Dimensions (cm) :

• Analog Magnetic Stirrer Heater - 21x31x10
• Digital Magnetic Stirrer Heater - 19x31x13
• Steel ball, 2 pieces - ---
• Frame - ---
• Brass ring 2 pieces, EN - ---
• Brass ring 2 pieces, ASTM ---
• Pouring Plate, EN, Metal ---
• Pouring Plate, ASTM, Brass ---
• Glass Beaker, 600 ml - 9x9x12,5
• Glass Thermometer; max 110 C - 3x3x30
• Glass Thermometer; max 360 C - 3x3x30
• ASTM 15C Thermometer; -2 (+80) C - 3x3x30
• ASTM 16C Thermometer; 30-200 C - 3x3x30

Weight (kg) :

• Analog Magnetic Stirrer Heater - 2,8
• Digital Magnetic Stirrer Heater - 4
• Steel ball, 2 pieces ---
• Frame ---
• Brass ring 2 pieces, EN ---
• Brass ring 2 pieces, ASTM ---
• Pouring Plate, EN, Metal ---
• Pouring Plate, ASTM, Brass ---
• Glass Beaker, 600 ml - 0,25
• Glass Thermometer; max - 110 C - 0,1
• Glass Thermometer; max - 360 C - 0,1
• ASTM 15C Thermometer; -2 (+80) C - 0,1
• ASTM 16C Thermometer; 30-200 C - 0,1

Power Supply :

• Analog Magnetic Stirrer Heater - 230 V, 50-60 Hz, 1 ph
• Digital Magnetic Stirrer Heater - 230 V, 50-60 Hz, 1 ph
• Steel ball, 2 pieces ---
• Frame ---
• Brass ring 2 pieces, EN ---
• Brass ring 2 pieces, ASTM ---
• Pouring Plate, EN, Metal ---
• Pouring Plate, ASTM, Brass ---
• Glass Beaker, 600 ml ---
• Glass Thermometer; max 110 C ---
• Glass Thermometer; max 360 C ---
• ASTM 15C Thermometer; -2 (+80) C ---
• ASTM 16C Thermometer; 30-200 C ---
