Roll Crusher

Usage :

• Suitable for grinding materials to produce fine mesh samples

Construction :

• Solid-Robust Construction

Frame :

• Made of Mild Steel

Rollers :

• Mn. Steel , Grade III, as per IS 276 specifications; 2 Nos.; Smooth Roller

Roller Size :

• 12 (dia.) x 8 (L) Inch / 300 (dia.) x 200 (L) mm approx.

Materials to be Crushed :

• Mn. Ore / Iron Ore

Materials Feed Size :

• 10-13 mm

Finish Size :

• 0.5 mm to 3 mm

Output Size :

• 1-2 mm

Capacity :

• 100 Kg/ Hr

Motor Capacity :

• 3 HP; 960 RPM

Drive Arrangement :

• V-Belt Pulley & V-Belts arrangement

Speed :

• 140-160 RPM

Power Supply :

• 440VAC, 50 Hz, Three Phase
