Roll Stability Tester for Fuel Testing Instrument

The Roll Stability Tester is designed to evaluate the shear stability of lubricating greases by measuring changes in worked penetration after two hours of rolling under controlled conditions. The test helps determine how mechanical working affects the consistency and performance of grease.

The apparatus rotates steel test cylinders at 10 or 165 rpm inside a thermostatically controlled chamber. A robust geared motor drives the rotation mechanism, while interchangeable sprockets allow convenient conversion between operating speeds.

The system features microprocessor-based PID temperature control, dual LED displays for actual and setpoint temperatures, and an overtemperature protection circuit. A balanced cast-aluminum fan and 1200 W heater provide efficient heat distribution. An optional high-temperature model extends the operating range to 160°C for specialized time-temperature testing.

Manufactured by Atico Export for reliable grease shear stability testing in lubricant research and quality control laboratories.

• Evaluation of lubricating grease shear stability
• Determination of changes in worked penetration
• Assessment of grease consistency after mechanical working
• Quality control of industrial and automotive greases
• High-temperature grease stability testing with the optional model

Operating Speed :

• 10 rpm or 165 rpm

Standard Maximum Temperature :

• 200°F (93°C)

High-Temperature Model :

• Up to 320°F (160°C)

Temperature Control Stability :

• ±2°F (±1°C)

Heating System :

• 1200 W heater

Drive System :

• Geared motor with interchangeable drive chain sprockets

Standard Accessories :

• Test cylinders with threaded end caps and O-ring seals
• Steel test rollers, 5 kg

Dimensions (L × W × H) :

• Single-unit: 16.5 × 18.375 × 15 inches (42 × 47 × 38 cm)
• Double-unit: 16.5 × 18.375 × 15 inches (42 × 47 × 38 cm)
• Four-unit: 25 × 18.375 × 15 inches (64 × 47 × 38 cm)

Net Weight :

• Single-unit: 107 lb (48.5 kg)
• Double-unit: 120 lb (54.4 kg)
• Four-unit: 187 lb (84.8 kg)

• Available in single-unit, double-unit, and four-unit models
• Optional high-temperature model
• Steel test cylinders with threaded end caps and O-ring seals
• Operating speeds of 10 or 165 rpm
• Microprocessor-based PID temperature control
• Dual LED displays for actual and setpoint temperatures
• Rapid temperature stabilization with minimal overshoot
• Automatic overtemperature cut-off protection
• Balanced cast-aluminum circulation fan
• 1200 W heating system
• Hinged cover with dial thermometer
• Shielded heaters and drive chain mechanism for operator safety
• Insulated steel cabinet with durable polyurethane enamel finish
• Optional RS232 communication software and ramp-to-set functionality
