Roller bearing faults Deluxe

Vibration analysis is a key tool in estimating the condition of a roller bearing. The slow change in the vibration spectrum provides indications of the remaining life of a bearing and can be used as a criterion for its replacement. The spectral distribution can deliver accurate information on the type and location of the damage.

• investigation of the vibrations of roller bearings
• roller bearing with damage to outer race
• roller bearing with damage to inner race
• roller bearing with damage to a roller body
• roller bearings with combined damage
• long-running roller bearings
• new and undamaged roller bearing
• drive motor with variable speed via frequency converter
• radial loading of bearings via adjustable loading device
• vibration isolation of the foundation plate using rubber elements
• instruments: optical speed sensor, acceleration sensor to record vibration
• software features: 2-channel oscilloscope; 2-channel FFT analyser; envelope analysis; run-up curve and order analysis
• software for data acquisition via USB under Windows 11
