Rotational Moment of Inertia Apparatus for Mechanics Physics Lab

This Rotational Moment of Inertia Apparatus for Mechanics Physics Lab is designed for studying rotational dynamics and determining the moment of inertia of rigid bodies using the three-string pendulum method. The apparatus employs a photoelectric sensing system and a precision electronic timer to accurately measure oscillation periods, enabling reliable calculation of rotational moment of inertia. Through practical experimentation, students can investigate the influence of mass distribution and axis position on rotational motion while gaining a deeper understanding of rotational mechanics.

Manufactured by Atico Export India.

Experimental Principle and Content

• Measure the Moment of Inertia of Rigid Bodies Using the Three-String Pendulum Method
• Compare the Moments of Inertia of Objects with Equal Mass but Different Mass Distributions
• Verify the Parallel Axis Theorem
• Investigate the Relationship Between Mass Distribution and Rotational Resistance
• Study the Effect of Axis Position on Moment of Inertia

Educational Objectives

• Understand the Principles of Rotational Motion and Moment of Inertia
• Learn Experimental Techniques for Measuring Rotational Properties
• Analyze the Influence of Mass Distribution on Rotational Dynamics
• Explore Practical Applications of the Parallel Axis Theorem

Pendulum String Length :

• Greater Than 500 mm

Timing Resolution :

• 1 ms

Preset Count Number :

• Less Than 66

Specimens :

• 2 Cylinders
• 1 Circular Disc
• 1 Circular Ring

Standard Supply

• Main Unit (Including Base, Slider, Hanging Arm, Hanging Disc, Starting Disc, and Pendulum Strings) × 1
• Laser Diode × 1
• Receiver × 1
• Counting Timer × 1
• Connection Wires × 2
• Circular Lever × 1
• Cylindrical Specimens × 2
• Disc Specimen × 1
• Ring Specimen × 1
• Instruction Manual × 1

• Optical Rail for Easy Alignment and Adjustment
• High Measurement Accuracy
• User-Friendly Operation
• Cost-Effective Experimental System
