Rust Preventing Characteristics Oil Bath for Oil Fuel and Petroleum Testing Instruments

The Rust Preventing Characteristics Tester determines the ability of lubricants to prevent rusting of metal surfaces. It is suitable for steam turbine oils, gear oils, hydraulic oils, and other inhibited mineral oils. Testing is performed by immersing a steel test specimen in a heated mixture of sample oil and water while continuously stirring the mixture. After the test period, the specimen is examined for rust formation. The instrument supports the ASTM D665 vertical specimen method and the ASTM D3603 horizontal disc method, which evaluates both horizontal and vertical test surfaces. The six-place constant-temperature bath accommodates six sample beakers and provides stirring at 1000 RPM. It features microprocessor PID temperature control, dual LED displays, and over-temperature protection. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for lubricant corrosion and rust prevention testing applications.

Testing Capacity:

• Six 400 mL sample beakers

Temperature Control:

• Maximum temperature: 104°C (220°F)
• Temperature control stability: ±0.5°C (±1°F)
• Microprocessor PID programmable temperature control
• Rapid temperature stabilization with minimal overshoot
• Dual LED displays for actual and setpoint temperatures
• Temperature display in °C or °F
• Automatic over-temperature protection with programmable cutoff

Stirring System:

• Stirring speed: 1000 RPM
• Stainless steel stirrer paddles
• Ball-bearing drive motor
• Improved pulley drive and roller-bearing arrangement
• Paddles can be raised and lowered for sample beaker placement
• Long-lasting polyester drive belt
• Removable steel guard protects drive-train components

Construction:

• Stainless steel bath
• Perforated support shelf for sample beakers
• Stainless steel or chemical-resistant polyurethane enamel exterior finishes

Drive Motor:

• 1/12 hp induction motor

Bath Medium:

• 11 gallons (41.6 L) white technical oil

Communication and Optional Features:

• Ramp-to-set temperature control and other enhanced features available at additional cost

Dimensions (L × W × H):

• 32.75 × 14.25 × 27 inches (83 × 36 × 69 cm)

Net Weight:

• 98 lbs (44.5 kg)
