Sample Splitter

A faultless and comparable analysis is closely linked to an accurate sample handling. Only a sample representative of the initial material can provide meaningful analysis results. Sample splitters ensure the representativeness of a sample and thus the reproducibility of the analysis.

The sample splitters are ideal for the on-site reduction of sample material. They are easy to use, easy to clean and do not need an electrical power supply.

FUNCTIONAL PRINCIPLE

With sample splitters, one of the receptacles is used to pour a well mixed sample evenly into the dividing head. The material runs through the alternately arranged passages in the opposite direction into the two collecting receptacles under the dividing head outlets. With every operation the feed sample is halved. This can be repeated as many times as necessary until the required dividing quantity has been obtained.

Applications :

• sampling and sample dividing

Slot size :

• RT 6.5: 6.3 mm
• RT 12.5: 12.5 mm
• RT 25: 25.0 mm
• RT 37.5: 37.5 mm
• RT 50: 50 mm
• RT 75: 75 mm

Number of slots :

• RT 6.5: 12
• RT 12.5: 18
• RT 25: 16
• RT 37.5: 12
• RT 50: 8
• RT 75: 6

Field of application :

• agriculture, biology, chemistry / plastics, construction materials, engineering / electronics, environment / recycling, food, geology / metallurgy, glass / ceramics, medicine / pharmaceuticals

Feed material :

• bulk materials

Material feed size :

• RT 6.5: ~ 4 mm
• RT 12.5: ~ 8 mm
• RT 25: ~ 16 mm
• RT 37.5: ~ 25 mm
• RT 50: ~ 33 mm
• RT 75: ~ 50 mm

Batch size / feed quantity :

• RT 6.5: <= 3 l
• RT 12.5: <= 3 l
• RT 25: <= 16 l
• RT 37.5: <= 16 l
• RT 50: <= 16 l
• RT 75: <= 16 l

Number of divisions :

• 2

W x H x D :

• RT 6.5: 30 x 27 x 25 cm
• RT 12.5: 30 x 27 x 25 cm
• RT 25: 62 x 42 x 26 cm
• RT 37.5: 62 x 42 x 26 cm
• RT 50: 62 x 42 x 26 cm
• RT 75: 62 x 42 x 26 cm

Net weight :

• RT 6.5: ~ 3.5 kg
• RT 12.5: ~ 3.5 kg
• RT 25: ~ 21.5 kg
• RT 37.5: ~ 21.5 kg
• RT 50: ~ 21.5 kg
• RT 75: ~ 21.5 kg

• For use in laboratory and on-site

• High-precision manual dividing process
