Sample Splitters Riffle Box

Electrostatically painted and they are supplied with 2 collecting pans.
Another model Mini Riffle Box is available as stainless steel.

Application :

• Used for the precise division into two representative portions of materials such as: aggregates, sand, gravel and similar.

Standards Compliance :

• Complied as per EN 932-1, EN 932-2, ASTM C702, BS 812-1, 1377-1, 1924-1

Dimensions (cm) :

• Riffle Box 2kg - 13x18x18
• Riffle Box 4,5kg - 15x20x25
• Riffle Box 6kg- 20x25x35
• Riffle Box 6,5kg - 20x29x35
• Riffle Box 11kg - 22x31x40
• Riffle Box 11kg - 23x32x42
• Riffle Box 12kg - 25x35x42
• Riffle Box 15kg - 23x42x45
• Riffle Box 16kg - 32x43x57
• Riffle Box 20kg - 32x45x59
• Riffle Box 27kg - 32x50x60
• Riffle Box 32kg - 36x60x60
• Riffle Box 35kg - 37x70x60
• Mini Riffle Box 1,4kg - --

Aperture (mm) :

• Riffle Box 2kg - 7
• Riffle Box 4,5kg - 10
• Riffle Box 6kg- 13
• Riffle Box 6,5kg - 15
• Riffle Box 11kg - 19
• Riffle Box 11kg - 20
• Riffle Box 12kg - 25
• Riffle Box 15kg - 30
• Riffle Box 16kg - 38
• Riffle Box 20kg - 45
• Riffle Box 27kg - 50
• Riffle Box 32kg - 64
• Riffle Box 35kg - 75
• Mini Riffle Box 1,4kg - 5

Number of Slots :

• Riffle Box 2kg - 12
• Riffle Box 4,5kg - 12
• Riffle Box 6kg - 12
• Riffle Box 6,5kg - 12
• Riffle Box 11kg - 10
• Riffle Box 11kg - 10
• Riffle Box 12kg - 10
• Riffle Box 15kg - 10
• Riffle Box 16kg - 8
• Riffle Box 20kg - 8
• Riffle Box 27kg - 8
• Riffle Box 32kg - 8
• Riffle Box 35kg - 8
• Mini Riffle Box 1,4kg - 16
