Sand Equivalent Shaker

• The unit provides a constant uniform shaking with automatic cycle test.Provides shaking action at the specified rate and stroke.
  Supplied complete with built-in timer that stops the shaker at the end of the test.

Standards Compliance :

• EN 933–8, ASTM D2419, AASHTO T176

Standard EN

• Horizontal Movement : 200 mm ° 10 mm
• Cycle : 200 mm ° 10 mm

Standard ASTM

• Horizontal Movement : 203.2 mm ° 1 mm
• Cycle : 175 ° 2 / min

Dimensions (cm) :

• AECE2263 - 22 ° 60 ° 32
• AECE2264 - 37 ° 94 ° 47

Weight (kg) :

• AECE2263 - 25 kg
• AECE2264 - 36 kg

Safety & control features :

• When opening cabinet–s door during shaker working, a micro switch automatically stops the machine.
