Scotch Yoke Mechanism Deluxe

The Scotch Yoke Mechanism, to demonstrate the behavior of a simple scoth yoke mechanism driven by a crank.

ATENG 12059 — Scotch Yoke Mechanism

Bench-top unit.

Anodized aluminum frame and panels made of painted steel.

Main metallic elements made of stainless steel.

• The “ATENG 12059” unit mainly consists of:
  Rotary element (crank) with a graduated disc to read the angle.
  Piston with a millimeter scale to measure the linear motion.
  Vertical pivot links the rotary element (crank) and the piston.
  Angle measurement indicator.
