SCR Single Phase Dual Converter Trainer

Power Supply:

• Power Supply: +15V, 150mA
• Isolated Supply: 0–220V/110V/24V at 1A
• Operated on mains power: 230V, 50Hz ±10%

Digital Meters:

• Voltmeter: 2000V AC
• Voltmeter: 2000V DC
• Ammeter: 2A DC

Components Mounted on the Panels:

• SCR: 8N08
• Diode: BA159
• AC Phase Control by Gate Control Firing Circuit
• Snubber Circuit

LOAD:

• 1A Inductive Load
• Resistive Load: 200 Ohm, 20W
• Lamp Load: 230V, 60W

ACCESSORIES

• Patch cords
• Instruction manual

Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.

• Protection Cover
• Front panel built with high-class insulated printed circuit board sheet with printed circuits and symbols
• Instruction manual
• Patch cords 2 mm and 4 mm
• High-voltage test points provided with 4 mm safety sockets
• Trainer housed in a metal cabinet
• Trainer size: 15 × 11"
