SCR Single Phase Half Controlled Rectifier Ramp Firing

The SCR Single Phase Half Controlled Rectifier Ramp Firing is designed for practical study of SCR-based AC phase control and controlled power conversion. It provides a suitable platform for understanding SCR triggering, phase-angle control, inductive and resistive load behavior, and waveform analysis through hands-on experiments. The trainer includes a gate control firing circuit, inductive and resistive loads, a digital power supply section, and a potential divider for CRO measurements. Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.

Power Supplies:

• +15 V / 150 mA.
• Isolated supply: 0–12 V AC, 500 mA.
• Mains operated: 230 V, 50 Hz ±10%.

Components Mounted on Panel:

• SCR.
• AC phase control by gate control firing circuit.
• Inductive load using 12 V DC motor.
• Resistive load using variable 5 W resistor.

• 10:1 potential divider for CRO.
• Protective cover.
• Bulb provided as load.
• Fuse protection against short-circuit conditions.
• Front panel with high-class insulated printed circuit board featuring clearly printed circuits and symbols.
• Instruction manual.
• 4 mm patch cords.
• High-voltage test points with 4 mm sockets.
• Housed in a metal cabinet.
• Trainer size: 12 × 8 inches.
