Semi Automatic Calorimeter for Oil Fuel and Petroleum Testing Instruments

The Isoperibolic Oxygen Bomb Calorimeter determines the heat of combustion of a weighed sample by burning it in an oxygen pressure vessel under controlled conditions. The heat of combustion is calculated from temperature measurements taken before, during, and after combustion, with appropriate thermochemical and heat-transfer corrections. The instrument features a removable oxygen pressure vessel and bucket for convenient sample loading and water filling. A controlled-temperature jacket surrounds the combustion vessel and bucket, while a microprocessor-based controller monitors both temperatures and continuously applies real-time heat-leak corrections. Designed for high-precision quality control, research, and development applications, the system supports multiple pressure vessel configurations for different energy release requirements. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for calorific value and combustion testing applications.

Measurement Type:

• Isoperibolic calorimetry

Precision Classification:

• 0.05–0.10%

Throughput:

• 4–6 tests per hour
• Six tests per hour requires a second pressure vessel and bucket
• Operator time per test: approximately 6 minutes

Accuracy:

• 6318 ± 19 cal/g for a single analysis of the standard

Number of Vessels:

• Up to 4

Oxygen Filling:

• Automatic

Bucket Filling and Pressure Vessel Washing:

• Manual

Temperature Measurement:

• Temperature resolution: 0.0001°C
• Microprocessor-based monitoring of bucket and jacket temperatures
• Continuous real-time heat-leak corrections

Data Storage and Communication:

• Memory capacity: 1000 tests
• Ethernet or USB connection for printer and balance
• Ethernet network connection
• SD memory and Ethernet network communications

Standard Accessories:

• Alloy 20 oxygen pressure vessel
• Oxygen regulator
• Calibration standards, range 5000–8000 calories
• Pressure vessel maintenance and repair kit
