SEMI-CIRCULAR ARCH

Semi-circular arch specimen for structural analysis experiments involving arch behaviour under distributed and point loading.

• Section: 40 × 8 mm uniform section
• Span: 1 m
• Rise: 0.5 m
• End conditions: Pinned and roller arch ends
• Load points: 7 equi-spaced vertical loading points at 125 mm intervals
• Model analysis pins fitted at each load point
