SHEARING FORCE APPARATUS

A length of material supported horizontally and carrying vertical loads is called a beam. The loading causes bending and transverse shearing. The loads and reactions are the external forces acting on the beam – they must be in equilibrium. Learn about SHEARING FORCE APPARATUS exporters for optimal educational outcomes.. However, the strength of the beam depends on internal forces.

• Beam lengths: 660mm and 330mm
• Beam cross section: 51 x 38mm
• 50mm graduations on beams
• Weights set: 3 x 2N, 3 x 5N, 3 x 10N
• 6kg Spring Balance
