Sieve Shaker

The sieve shaker imparts a circular motion to the material being sieved so that it makes a slow progression over the surface of the sieve.
They are equipped with a dynamic power source which ensures the right vibration is imparted to the sieves and sample for fast, accurate and reproducible tests. The vertical movement is fixed to ensure the sample spends maximum time on the sieve surface. The unique vibratory action also helps keep the apertures clean and free from binding.
The shaker is fitted with a very efficient clamping device that ensures sieves are held firmly without over-tightening and allows them to be quickly removed and replaced.
The shaker is fitted with digital timer which can be pre-set for any duration up to 99 minutes.
Different models are available according to the sieve diameters.

• They are ideal for heavy duty applications when heavy or large bulk samples have to be analyzed.
• Wet sieving kits in the appropriate sizes may be used with this shaker.
• Noise reduction cabinet should be ordered separately.

Standards Compliance :

• Complied as per EN 932-5, ISO 565, ISO 3310-1, ISO 3310-2, ASTM E11, E323, BS 410-1, BS 410-2, EN 1339, EN 1367-1; TS 2824

Sieve Diameter :

• Sieve Capacity

200 mm :

• 15 pieces

300 mm :

• 10 pieces
• plus lid and receiver

400 mm :

• 7 pieces

Dimensions (cm) :

• Sieve Shaker, Time Controlled 30kg - 52x73x40
• Sieve Shaker, Time Controlled 30kg - 52x73x40
• Sieve Shaker, Time Controlled 30kg - 72x93x40
• Sieve Shaker with Frequency Controlled 30kg - 52x73x40
• Sieve Shaker with Frequency Controlled 50kg - 52x73x40
• Sieve Shaker with Frequency Controlled 50kg - 72x93x40

Sieve Dia. Capacity (mm) :

• Sieve Shaker, Time Controlled 30kg - 200/300
• Sieve Shaker, Time Controlled 30kg - 200/8"/250/300/12"/315
• Sieve Shaker, Time Controlled 30kg - 200/8"/250/300/12"/315/400/450
• Sieve Shaker with Frequency Controlled 30kg - 200/300
• Sieve Shaker with Frequency Controlled 50kg - 200/8"/250/300/12"/315
• Sieve Shaker with Frequency Controlled 50kg - 200/8"/250/300/12"/315/400/450

Power Supply :

• Sieve Shaker, Time Controlled 30kg - 220 V, 50 Hz, 1 ph
• Sieve Shaker, Time Controlled 30kg - 220 V, 50 Hz, 1 ph
• Sieve Shaker, Time Controlled 30kg - 220 V, 50 Hz, 1 ph
• Sieve Shaker with Frequency Controlled 30kg - 220 V, 50-60 Hz, 1 ph
• Sieve Shaker with Frequency Controlled 50kg - 220 V, 50-60 Hz, 1 ph
• Sieve Shaker with Frequency Controlled 50kg - 220 V, 50-60 Hz, 1 ph
