Simple Harmonic Motion and Spring Constant for Mechanics Physics Lab

This Simple Harmonic Motion and Spring Constant for Mechanics Physics Lab is designed for studying the principles of simple harmonic motion and determining the spring constant through both static and dynamic measurement methods. The apparatus combines a Jolly balance equipped with a precision reading system, including a pointer, reflective mirror, and vernier scale, with an integrated Hall switch sensor and electronic timer for accurate oscillation period measurements. The system provides students with a comprehensive understanding of spring behavior, Hooke’s Law, and oscillatory motion through practical experimentation.

Physics Lab Experiments from Atico Exports.

Experimental Principle and Content

• Verify Hooke’s Law by Studying the Relationship Between Force and Displacement
• Determine the Spring Constant Using Static Measurement Methods
• Investigate the Characteristics of Simple Harmonic Motion in a Spring-Mass System
• Measure Oscillation Periods and Calculate the Spring Constant
• Study the Working Principle and Application of the Hall Switch Sensor

Educational Objectives

• Understand the Fundamentals of Hooke’s Law
• Analyze the Relationship Between Restoring Force and Displacement
• Study the Principles of Simple Harmonic Motion
• Learn Accurate Measurement Techniques Using Modern Sensing Devices
• Develop Practical Laboratory Skills in Data Collection and Analysis

Jolly Balance Ruler :

• Measuring Range: 0–551 mm
• Reading Accuracy: 0.02 mm

Counter / Timer :

• Accuracy: 1 ms
• Storage Function Included

Spring :

• Wire Diameter: 0.5 mm
• Outer Diameter: 12 mm

Integrated Hall Switch Sensor :

• Critical Distance: 9 mm

Magnetic Steel Disc :

• Diameter: 12 mm
• Thickness: 2 mm

Weights :

• 1 g × 10 pcs
• 20 g × 1 pc
• 50 g × 1 pc

Standard Supply

• Jolly Balance with Reading Device × 1
• Counter / Timer × 1
• Spring × 1
• Integrated Hall Switch Sensor × 1
• Magnetic Steel Disc × 1
• Weights Set × 12 pcs
• Instruction Manual × 1

• High-Precision Timing Device
• Accurate Reading System with Vernier Scale
• Reliable Experimental Performance
• Cost-Effective Educational Apparatus
