Simple Harmonic Motion Unit

This Simple Harmonic Motion Unit, allows many experiments using several pendulums and devices, such as different types of pendulums (simple, bifilar, trifilar and Kater’s pendulum) and springs.

ATENG 12112 — Simple Harmonic Motion Unit

Bench-top unit with adjustable legs.

Anodized aluminum frame and panel in painted steel.

• The “ATENG 12112” unit mainly consists of:
  Top plate (supports the pendulums).
  Bottom plate with goniometer.
• Storage suitecase that includes:
  Two simple pendulums (aluminum and brass).
  Rod pendulum as bifilar pendulum.
  Rod pendulum with equiangular separation as trifilar pendulum.
  Spring.
• Set of weights:
  Six weights of 50 g.
  Four weights of 150 g.
  Weights hanger.
  Stopwatch to measure the oscillation time. ATENG 12112 detail
  Ropes with carabiners to facilitate the suspension of pendulums.
  Tensors for greater accurate of the length to be fixed.
  Limiting plates to facilitate a correct adjustment of the supporting ropes.
  Kater’s pendulum.
• Graduated scale. L = 500 mm
