Single Glass Jacketed Reactor ALB358

Single Glass Jacketed Reactor is designed with a high-quality glass vessel for reliable chemical synthesis, mixing, and extraction applications. It provides precise temperature control, efficient stirring, and high vacuum performance to ensure stable and accurate reaction processes. Manufactured by Atico Export India.

Used for chemical synthesis, pharmaceutical formulation, extraction processes, university research, chemical and biological laboratories, biopharmaceutical industries, aerospace, and healthcare.

Capacity :

• 5 L

Glass Vessel Temperature Range :

• -80°C to 250°C

Bath Temperature Control Range :

• RT to 180°C

Temperature Measurement Accuracy :

• ±1°C

Stirring Speed :

• 0 to 800 rpm

Vacuum Degree :

• 0.098 MPa

Glass Vessel Diameter :

• Φ230 mm

Dropping Funnel Capacity :

• 500 mL

Stirring Motor Power :

• 90 W

Heating Power :

• 1.5 kW

Power Supply :

• 220 V / 50 Hz

Dimensions :

• (430 to 1030) × 330 × 1150 mm

Weight :

• 25 kg

• Borosilicate glass construction
• Digital control interface
• PTFE and fluororubber dual sealing system
• Brushless copper motor
• Stable and low-noise operation
