Single Glass Jacketed Reactor ALB360

Single Glass Jacketed Reactor is designed with a high-quality borosilicate glass vessel for reliable chemical synthesis, mixing, and extraction applications. It provides precise temperature control, efficient stirring, and high vacuum performance for consistent and accurate reaction processes. Manufactured by Atico Export India.

Used for chemical synthesis, pharmaceutical formulation, extraction processes, university research, chemical and biological laboratories, biopharmaceutical industries, aerospace, and healthcare.

Capacity :

• 20 L

Glass Vessel Temperature Range :

• -80°C to +250°C

Temperature Accuracy :

• ±1°C

Stirring Speed :

• 0 to 450 rpm

Vacuum Degree :

• 0.098 MPa

Glass Vessel Diameter :

• Φ355 mm

Dropping Funnel Capacity :

• 2 L

Stirring Motor Power :

• 120 W / 3

Heating Power :

• 5 kW

Power Supply :

• 220 V / 50 Hz

Dimensions :

• 810 × 540 × 1960 mm

Weight :

• 48 kg

• Robust construction
• PTFE and fluororubber dual sealing system
• Low-noise operation
• Easy to clean
• Reliable vacuum operation
