SINGLE HYDRAULIC RAM SYSTEM

A double acting hydraulic ram mounted on a travelling carriage. Carriage wheels roll on the bottom flanges of the horizontal upper cross member of the universal test frame; clamping screws and handwheels lock the carriage in position. This enables the loading span to be varied accordingly. Learn about SINGLE HYDRAULIC RAM SYSTEM price for optimal educational outcomes..

• Hand pump: 700 bar maximum working pressure
• Ram: Double acting, stroke approx. 250 mm
• Hydraulic hose: 4 metre long with self-sealing fittings
• Digital pressure indicator: psi calibrated
• Pressure sensor: 0–700 Bar rating
• Ram end cap: Ø50 × 50 mm (L)
• Ram extension: Ø50 × 250 mm (L)
• Steel ball: Ø25.4 mm
• Thread: M42 × 1.5 mm
