Single Phase AC Phase Control by Triac

The Single Phase AC Phase Control by Triac is designed for practical study of TRIAC-based AC phase control and gate triggering techniques. It provides a suitable platform for understanding TRIAC operation, phase-angle control, and AC power control through hands-on experimentation. The trainer includes a TRIAC, MOC 2031, and AC phase-control circuit using gate-control firing techniques. Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.

Power Supplies:

• +15 V / 150 mA.
• Isolated supply: 0–220 V at 2 A.
• Mains operated: 230 V, 50 Hz ±10%.

Components Mounted on Panel:

• TRIAC BT136.
• MOC 2031.
• AC phase control by gate control firing circuit.

Load:

• Bulb.

• 10:1 potential divider for CRO.
• Protective cover.
• Bulb provided as load.
• MCB and fuse protection against short-circuit conditions.
• Front panel with high-class insulated printed circuit board featuring clearly printed circuits and symbols.
• Instruction manual.
• 4 mm and 2 mm patch cords.
• High-voltage test points with 4 mm and 2 mm safety sockets.
• Housed in a metal cabinet.
• Trainer size: 12 × 8 inches.
