Single Phase Induction Motor

Single phase asynchronous induction motor designed for educational training, testing and analysis of motor performance in electrical machines laboratory.

Nominal Power:

• 375W (1/2 HP)

Nominal Voltage:

• 240VAC

Nominal Current:

• 2.0A

Nominal Speed:

• 1500 rpm

Frequency:

• 50Hz

Power Factor:

• 0.78

Winding Poles:

• 4

Terminals:

• 4mm Safety Socket

Mechanical Details :

• Coupling: Optional (Alignment needed for coupling to generator brake unit)
• Base Plate: Attachable to break load unit / generator unit

Accessories :

• Instructional & Experimental Manual Provided

Typical Experimental :

• Winding Resistance Measurement
• No-Load Test
• Speed Control
• Torque Speed Test
• Nominal Load and Over Load Test
• Magnetic Characteristics
• Electromechanical Characteristics
