Single Phase MOSFET Bridge Inverter Using PWM Technique

The Single Phase MOSFET Bridge Inverter Using PWM Technique is designed for studying single-phase inverter operation and pulse width modulation techniques. It provides a practical platform for understanding MOSFET switching, PWM pulse generation, frequency control, and DC-to-AC power conversion. The trainer includes protection features, a PWM pulse generator circuit, frequency control through a potentiometer, and a bulb load for practical demonstrations. The unit is housed in a metal cabinet with a clearly printed insulated circuit board for convenient operation. Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.

Power Supplies:

• +15 V / 150 mA.
• Isolated supply: 0–12 V at 2 A.
• Mains operated: 230 V, 50 Hz ±10%.

Components Mounted on Panel:

• MOSFET IRF540: 4 units.
• PWM pulse generator circuit.
• Frequency control through potentiometer.

Load:

• Bulb.

• Protective cover.
• Overload protection through circuit breaker.
• Fuse protection against short-circuit conditions.
• Front panel with high-class insulated printed circuit board featuring clearly printed circuits and symbols.
• Instruction manual.
• 2 mm patch cords.
• High-voltage test points with 2 mm sockets.
• Housed in a metal cabinet.
• Trainer size: 12 × 8 inches.
