Skid Resistance and Friction Tester Standard

Usage :

• Suitable for measurement of surface friction properties

Construction :

• Solid-Robust Construction

Rocker Weight :**

• 1500 gms. +/- 30 gms.

Distance between Rocking Centre and Center of Gravity :

• 410 mm, +/- 5 mm

Pavement Positive Static Pressure :

• 22.2kn, +/-0.5 kn

Base Plate Dimension :

• 700 x 360 x 70 mm

Accessories :

• Additional Scale : Provided for tests on polished stone value specimens

• Rubber Slides : 6 Nos. (for site use)

• Thermometer :Range : 10 to +110°C (for surface temperature measurement)

• Washing Bottle : Capacity : 1 Ltr. (for surface wetting)

• Tool Set : Provided with case

• Rule : Provided (for sliding length verification)

Standards Compliance :

• EN 13036-4 (Also Conforming to EN 1097-8, ASTM E103)
