Slider Crank Mechanism Deluxe

The Slider Crank Mechanism, is an example of slider-crank mechanism.

ATENG 12058 — Slider Crank Mechanism

Bench-top unit.

Anodized aluminum frame and panels made of painted steel.

Main metallic elements made of stainless steel.

• The “ATENG 12058” unit mainly consists of:
  Rotary element (crank) with a graduated disc and indicator to read the angle.
  Rigid bar with a millimeter scale to measure the linear motion.
  ATENG 12058 detail
  Two connecting rods of different length.
