Soil Auger (Motorised)

Standards Compliance :

• Complied as per ASTM D420, ASTM D1452, AASHTO T86, AASHTO T202, CNR A VI N.25

Application :

• Designed for soil investigations and to obtain representative samples.

Models Available :

Two models are available

• AECE2568/A Model Motorised Soil Auger is 2-stroke, single-person bicycle with arms and gasoline.
• AECE2568/B Model Motorised Soil Auger is is 2-stroke, double-person bicycle with arms and gasoline.

Common Features (Both Models) :

• In both models, the air filter is atmospheric, crank type bearing and the working system is a rope automatic starter.

Ordering Information :

• Soil Auger Bit should be ordered separately.

Height :

• AECE2568/A - 100 cm
• AECE2568/B - 100 cm

Drill length :

• AECE2568/A - 80 cm
• AECE2568/B - 80 cm

Engine power :

• AECE2568/A - 3.1 hp
• AECE2568/B - 4.5 hp

Engine capacity :

• AECE2568/A - 52 cc
• AECE2568/B - 68 cc

Gearbox :

• AECE2568/A - Oil-bearing
• AECE2568/B - Oil-bearing

Output gearbox rate :

• AECE2568/A - 34:1
• AECE2568/B - 34:1

Weight (without auger bit) :

• AECE2568/A - 14.5 kg
• AECE2568/B - 16.5 kg
