Soil Electrical Density Gauge (Non-Nuclear) - Touch Screen

The Electrical Density Gauge (EDG) is a nuclear-free alternative for determining the moisture and density of compacted soils used in road beds and foundations.The EDG is a portable, battery-powered instrument capable of being used anywhere without the concerns and regulations associated with nuclear safety.

OPERATIONAL FEATURES :

Status Bar :

• Displays GPS status, battery voltage, low battery and date and time.

Storage :

• Built-in 512MB memory, stores up to 40000 project measurement points with details, and up to 200 soil models.
  Data Logging: When enabled, stores all measurements taken in single or average modes. (Status Bar Icon)

Reports :

• Easily download data to be imported into Excel.

GPS Control :

• When activated will display latitude and longitude positions, number of satellites the gauge is connected to as well as the UTC date and time, also available in UTM format. GPS information will store with each measurement when Data Save and GPS feature is enabled. (Status Bar Icon)

Update Software :

• One touch upload of new software using a USB memory stick.

Data Management :

• Quickly access, download or delete your Project data.

Set Time & Date :

• Quick time and date setup, MM/DD/YY and DD/MM/YY formats

Units :

• Interchangeable settings for Density (kg/m3, lb/ft3), Temp (°C, °F), Depth (in, mm) and Stone size (in, mm)
• Enhanced customer support: Diagnostic screen to aid in factory Support
• User Programmable Target Density: Used for calculating % compaction

Standards Compliance :

• Complied as per ASTM D7830

Dimensions (mm) :

• 260°260°237

Weight (kg) :

• 3.25

OPERATIONAL SPECIFICATIONS :

MODES :

Single :

• Reading time less than five (5) seconds. Stores Data.

Average :

• Averages five (5) readings and stores data including location, date and time.

Continuous :

• Instantaneous density readings.

FUNCTIONS :

• Wet & Dry Density, % Compaction, % Moisture

SOIL SPECIFICATIONS :

• Designed to operate with standard soils used in civil construction projects.

Requires inputs from standard :

• Standard Test Methods for Liquid Limit, Plastic Limit, and Plasticity Index of Soils (ASTM D4318)
• Particle Size Distribution (ASTM D422)
• Proctor Test (ASTM D698 and D1557)

Operating Temperature :

• 7°C to 43°C (with temperature compensation)

MEASUREMENT SPECIFICATIONS :

Sensing Area :

• 260mm diameter base allows optimum Measurement on fine and coarse material types.

Measurement Depth :

• 50-300 mm

Measurement Display :

• Density % Compaction, Surface Temperature, Mix Name and Project Name

ELECTRICAL SPECIFICATIONS :

• Microprocessor Controlled

Battery :

• 13000mAh ternary lithium battery

Battery Time :

• 15h

Battery Charger :

• DC5V 2A

Computer Ports :

• 1 USB Port

• 7.0 in. full color graphics driven user interface, touch screen operation, easy to use.
• New Status Bar feature, displays GPS status, data save status, available battery voltage, low battery status and date and time.
• New data management feature, quickly Access, download, or delete your Project data.
• Ability to download files from the device via USB drive.
• Fast, reliable, accurate Material density and compaction test, and repeatable readings in real time, user friendly, cost effective.
• No additional calibration is required and field testing can be performed directly users only need to input the corresponding data to create the soil model procedure.
• The data can be read accurately in 5 seconds, with higher precision and better stability.
• Non-nuclear means no badges, licenses or storage and transport concerns.
