Solid density Physics Lab Experiment Setup

This experiment system is designed for studying the operating principles and performance characteristics of resistance strain load sensors. It enables users to investigate sensor response, signal conditioning techniques, and load measurement applications. The system also supports the development of solid density measurement methods using strain-based sensing technology, providing a practical platform for instrumentation and measurement experiments.

Physics Lab Experiments from Atico Exports.

Experimental Principle and Content

• Study of the Basic Characteristics of Resistance Strain Load Sensors
• Design and Development of Solid Density Measurement Methods

Sensor Power Supply :

• 6–12 V
• Continuously Adjustable
• 3½-Digit Digital Display

DC Voltage Measurement :

• Dual Ranges: 0–199.99 mV
• 0–19.99 V
• 3½-Digit Digital Display

DC Voltage Output :

• ±12 V
• 0.5 A

Operational Amplifier Module :

• Experimental Template with Continuously Adjustable Gain
