Soxhlet Extraction Water Bath 6 Position

The Soxhlet Water Bath is designed for precise and uniform heating during Soxhlet extraction procedures in laboratory environments. It features a six-hole operating system with independently controlled heating positions for simultaneous sample processing. Equipped with a PID temperature controller, it delivers accurate temperature regulation, while the adjustable concentric rings accommodate extraction flasks of various sizes. The LED display provides clear temperature monitoring, ensuring reliable and efficient laboratory operation. Manufactured by Atico Export India.

• Pharmaceutical laboratories
• Clinical laboratories
• Biomedical laboratories
• Chemical laboratories
• Soxhlet extraction processes
• Sample extraction and heating
• Research and development laboratories
• Educational laboratories

Capacity :

• 6-Hole Operating Type

Bath Dimensions :

• 890 × 150 × 100 mm

External Dimensions :

• 950 × 250 × 210 mm

Heater Capacity :

• 2000 W

Temperature Range :

• 5°C to 98°C

Temperature Sensor :

• PT-100 Ω

Top Opening Diameter :

• Ø110 mm

Power Supply :

• AC 220 V, 50 Hz / 60 Hz, Single Phase

• PID temperature controller
• LED display for temperature monitoring
• Adjustable opening rings
• Flask support frame and clamp
• SSR temperature regulation
• Uniform temperature distribution
• Accurate temperature control
• Suitable for different flask sizes
• Durable laboratory construction
