Electron Beam Tube :
- Diameter: 153 mm.
- Filled with inert gas.
- Integrated measurement scale.
- Scale Length: 90 mm.
Rotatable Tube Mount :
- Rotation Range: 350°.
- Graduated angle indication.
Deflection Voltage Supply :
- Adjustable Range: 50–250 V.
- Continuously variable output.
Acceleration Voltage Supply :
- Adjustable Range: 0–250 V.
- Built-in current-limiting protection.
- Digital voltmeter display.
- Resolution: 1 V.
Excitation Current Supply :
- Adjustable Range: 0–1.1 A.
- Digital ammeter display.
- Resolution: 1 mA.
Helmholtz Coil :
- Effective Radius: 140 mm.
- Turns per Coil: 300.
Enclosure :
- Solid wood observation cabinet.
- Dimensions: 300 × 345 × 475 mm.
Measurement Accuracy :
- Electron charge-to-mass ratio determination error better than 3%.
Designed For :
- Physics Lab Experiments from Atico Exports.
