Split Phase Induction Motor 370W

Single phase asynchronous induction motor with split phase construction designed for training, performance analysis and experimental studies in electrical machines laboratory.

Phase :

• Single Phase

Nominal Power :

• 370W (1/2 HP)

Nominal Voltage :

• 220 – 240VAC

Nominal Current :

• 4.5A

Pole :

• 2

Nominal Speed :

• 1450 rpm

Frequency :

• 50Hz

Cooling Method :

• Self Cooled

Terminals :

• 4mm Safety Socket

Mechanical Details :

• Coupling : Optional (Alignment needed for coupling to generator brake unit)
• Base Plate : Attachable to break load unit / generator unit

Accessories :

• Instructional & Experimental Manual Provided

Typical Experimental :

• No-Load Test
• Speed Control
• Torque Speed Test
• Nominal Load and Over Load Test
• Electromechanical Characteristics
